Taegutec TDXY 3E-0.4 TT9080

Product Code: 6304569

$42.16$38.33 Ex. GST

Product Code: 6304569 SKU 6304569 Categories Carbide, CUTTING TOOLS (HSS & Carbide), INDEXABLE INSERTS

Taegutec TDXY 3E-0.4 TT9080

Taegutec TDXY 3E-0.4 TT9080 - Image 2

Taegutec TDXY 3E-0.4 TT9080 - Image 3

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Double-ended pressed type multi functional inserts for external/internal/face grooving/turning especially suitable for high feed side turning & face grooving

Additional information

Weight	0.0040 kg
Dimensions
barcode
Additional Information	Cutting Width (CW): 3 mm Applicable Material:, Steel, Stainless Steel, Super-Alloys / Titanium, Corner Radius (RE): 0.4 mm Overall Length (OAL): 20 mm Thread Pitch Maximum (TPX): 0 mm Insert Seat Size Code (SSC): 3 Coating: TiAlN+TiN Measurement Type: Metric Grade: TT9080 Body Material: Carbide Cutting Edge Material: Carbide Unit: M Application:, Ext. Grooving, Ext. Grooving & Turning, Face Grooving, Face Grooving & Turning, Face Grooving Along Shaft, Inserts, Int. Face Grooving, Int. Face Grooving & Turning, Int. Groove & Turn, Int. Grooving, Parting

Brand

Taegutec
