Boring bars without coolant hole for internal grooving & turning
Additional information
Weight
1.3880 kg
Dimensions
barcode
Additional Information
Cutting Depth Maximum (CDX): 4.7 mm
Overall Length (OAL): 250 mm
Shank Width (B): 14 mm
Application:, Int. Groove & Turn, Int. Grooving, Int. Profiling, Minimum Bore Diameter (DMIN): 31 mm
Body Material: Steel
Functional Width (WF): 20.8 mm
Measurement Type: Metric
Head Length (LH): 60 mm
Unit: M
