Taegutec XNMG 110512 FGP TT8105B

Applicable Material:, Steel, Grade: TT8105B
Application:, Ext 100° App 70°Diamond, Ext 93° App 70°Diamond, Inserts, Int 100° App 70° Diamond, Int 93° App 70° Diamond, Min D.O.C.: 0.35 mm
Corner Radius (RE): 1.2 mm
Depth of Cut Maximum (APMX): 2 mm
Cutting Edge Length (L): 11.82 mm
Min. Turning Feed (ft(min)): 0.15 mm/rev
Insert Thickness (S): 5.56 mm
Max. Turning Feed (ft(max)): 0.4 mm/rev
Inscribed Circle Diameter (IC): 11.11 mm
Measurement Type: Metric
Cutting Edge Material: Carbide
Body Material: Carbide
Coating: TiCN-Al203-TiN
Unit: M
