TOLEDO DIAL INDICATOR ANALOGUE 0.01X10MM

Product Code: 322100

$185.16$168.33 Ex. GST

Product Code: 322100 SKU 322100 Category

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

High precision expert dial gauges for precision measuring work
Dial face with O-ring and internal housing sealing ensures unit is waterproof and dustproof
Shock-proof mechanism prevents damage to the internal gears if the spindle is pushed abruptly
Hardened SK quenched steel stem with specialty fastening to eliminate failure
Superior quality spindle rack, pinions and gear trains ensure longevity
Easy read design incorporates white dial face with black graduations and pointer needle
Knurled Bezel provides a firm and secure grip
Securely fitted back cover with four locking screws enables lug to rotate at 90° angles
Manufactured to JIS B 7503

Additional information

Weight 0.0000 kg
barcode

9300784058084

Additional Information

Specifications: â–  Type: Metric
â–  Graduation Range: 0.01 x 10mm
■ Reading: ±0-50-100
â–  Indication Error:
1/10 Revolution – 6μm
1/2 Revolution – ±7μm
One Revolution – ±8μm
Two Revolution – ±10μm
Full Measuring Range – ±10μm
■ Retrace Error: 4μm
■ Repeatability: 5μm
â–  Measuring Force: < 1.4N

Brand

TOLEDO
