Guhring Metric Fine M10 x 1.0 Spiral Flute Tap HSS-e Blue Band For Blind holes Made in Germany

Product Code: 2864 10,005

$122.46$111.33 Ex. GST

Product Code: 2864 10,005 SKU 2864 10,005 Categories , ,
Guhring Metric Fine M10 x 1.0 Spiral Flute Tap HSS-e Blue Band For Blind holes Made in Germany
Guhring Metric Fine M10 x 1.0 Spiral Flute Tap HSS-e Blue Band For Blind holes Made in Germany - Image 2
Guhring Metric Fine M10 x 1.0 Spiral Flute Tap HSS-e Blue Band For Blind holes Made in Germany - Image 3

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Enhance your precision and efficiency with the Guhring Metric Fine Blue Ring Spiral Flute Taps. The steam tempered design increases durability and longevity, providing a reliable tool to conquer any task. Elevate your workmanship and achieve superior results!

Spiral flute taps are primary for machine tapping & Ideal for blind holes.

HSS APPLICATIONS

Primary for machine tapping
Ideal for blind holes
Great for cutting new threads
Suited for use in a variety of ferrous and non-ferrous materials
Blue Ring for cutting – Stainless and acid resistant steels, Austentic, Marttensitic
HSS TECHNICAL DATA

Made from High Speed Steel
Standard – DIN 374
Tolerance – ISO2 / 6H
Surface – Steam Tempered
Guhring No. 2864

Additional information

Weight 0.0300 kg
Dimensions
barcode
Additional Information

Connection code machine side: Straight shank
Internal cooling: Without
Norm: DIN 374
Surface: Steam tempered
Discount group: 103
Type: 2864
Cutting direction: Right-hand
Type: VA R40
Material: HSS-E
Additional information: Internal threading
Form: C
Coloured ring: Blue ring
Threads: MF
Tolerance class thread: ISO2/6H
Hole type: Blind hole
Groove: 40° right-hand helix
Chamfer lead length: 2-3
Code no.: 10.005
Weight: 0.030
No of cutting edges: 3
Total length: 90.000
Thread length: 11.000
Groove length: 31.000
Usable length: 35.000
Norm 2: DIN 2184-1
Wrench opening 1: 5.500
Core hole Ø: 9.00
Shank Ø: 7.000
Nominal dimension thread: M10 x 1
Pitch: 1.000
External Ø: 10.060
Reach length: 67.000
Statistical goods number: 82074010
