Guhring Metric M20 x 2.5 Gun Nose Tap HSS-e-PM Blue Band For Thru holes Made in Germany

Product Code: 879 20,000

$251.61$228.74 Ex. GST

Product Code: 879 20,000 SKU 879 20,000 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Enhance your precision and efficiency with the Guhring Metric Blue Ring Gun Nose Taps. These high-performance gun taps are designed with precision and durability in mind, allowing for efficient and accurate threading. Upgrade your tapping game with Guhring’s reliable and effective gun taps.

Gun Nose taps are primary for machine tapping & Ideal for through holes.

HSS APPLICATIONS

Primary for machine tapping
Ideal for through holes as the tap pushes the swarf forwards
Great for cutting new threads
Suited for use in a variety of ferrous and non-ferrous materials
Blue Ring for cutting – Stainless and acid resistant steels, Austentic, Marttensitic
HSS TECHNICAL DATA

Made from High Speed Steel
Standard – DIN 371
Tolerance – ISO2 / 6H
Surface – Bright Finish
Guhring No. 879

Additional information

Weight 0.1960 kg
Dimensions
barcode
Additional Information

Connection code machine side: straight shank
Internal cooling: without
Norm: DIN 376
Surface: bright
Discount group: 103
Type: 879
Cutting direction: right-hand
Type: VA
Material: HSS-E-PM
Additional information: Internal threading
Form: B
Coloured ring: blue ring
Threads: M
Tolerance class thread: ISO2/6H
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 20
Weight: 0.196
No of cutting edges: 4
Total length: 140
Thread length: 32
Groove length: 58
Usable length: 62
Norm 2: DIN 2184-1
Wrench opening 1: 12
Neck Ø: 15.8
Core hole Ø: 17.5
Shank Ø: 16
Nominal dimension thread: M20
Pitch: 2.5
External Ø: 20.1
Reach length: 69
Statistical goods number: 82074010

Brand

Guhring
